8 ports per card. 2 ports have power failure transfer. 1 card requires 1 free slot. 1 optional (KX-TDA0193) 8 port caller ID card can be mounted to support caller ID. Please refer to Charts 1, 2, 3 and 4 prior to configuring a system. 85033-4 KX-TDA018116 PORT LOOP START CO TRUNK CARD.
Kx-tde100 Specifications Free Slots Slot Machines
Software Version
- KX-NCP500 / 1000 PBMPR Version 6.0
- KX-TDE100 / 200 PMMPR Version 6.0
- KX-TDE600 PGMPR Version 6.0
System Capacity
Maximum Number of Trunks and Extensions
The PBX supports the following number of trunks and extensions.
KX-NCP Series
Kx-tde100 Specifications Free Slots Video Poker
| Type | KX-NCP500 / KX-NCP1000 |
| Total Number of Trunks | 128 |
|---|---|
| Trunk (Physical Trunk Card) | 64 |
| Trunk (Virtual Trunk Card) | 64 |
| H.323 Trunks | 32 |
| SIP Trunks | 64 |
| Total Number of Extensions | 172 |
| Extension (Physical Extension Card) | 44 |
| Extension (Virtual Extension Card) | 128 |
| IP-PT and IP Software Phone | 128 |
| SIP Phone | 128 |
Scroll
KX-TDE Series
| Type | KX-TDE100 | KX-TDE200 | KX-TDE600 | |||
| Basic System | 2-shelf System | 3-shelf System | 4-shelf System | |||
| Total Number of Trunks | 128 | 128 | 224 | 384 | 544 | 640 |
|---|---|---|---|---|---|---|
| Trunk (Physical Trunk Card) | 120 | 128 | 160 | 320 | 480 | 640 |
| Trunk (Virtual Trunk Card) | 64 | 64 | 64 | 64 | 64 | 64 |
| H.323 trunks | 32 | 32 | 32 | 32 | 32 | 32 |
| SIP trunks | 64 | 64 | 64 | 64 | 64 | 64 |
| Total Number of Extensions | 256 | 256 | 432 | 736 | 1008 | 1152 |
| Extension (Physical Extension Card) | 160 | 256 | 304 | 608 | 880 | 1120 |
| Extension (Virtual Extension Card) | 128 | 128 | 128 | 128 | 128 | 128 |
| IP-PT and IP Software Phone | 128 | 128 | 128 | 128 | 128 | 128 |
| SIP Extension | 128 | 128 | 128 | 128 | 128 | 128 |
Scroll
* The maximum number of PTs in the whole system is limited to 640.
Kx-tde100 Specifications Free Slots No Deposit
Maximum Terminal Equipment
The following shows the number of each terminal equipment type supported by the PBX.
KX-NCP Series
| Terminal Equipment Type | KX-NCP1000 |
| Telephone | 172 |
|---|---|
| SLT | 36 |
| KX-DT300 / KX-T7600 series DPT | 40 |
| Other DPT | 10 |
| APT | 4 |
| IP-PT*1 | 128*2 |
| SIP Extension | 128 |
| DSS console | 8 |
| CS | 21*3 |
| PT-interface CS (2-channel) | 11 |
| PT-interface CS (8-channel) | 5 |
| IP-CS (8-channel) | 16 |
| PS | 64 |
| Voice Processing System (VPS) | 2 |
| Doorphone | 16*4 |
| Door Opener | 16 |
| External Sensor | 16 |
| External Relay | 16 |
Scroll
*1 KX-NT400, KX-NT300 series, and KX-NT265 (software version 2.00 or later only)
*2 For the KX-NT400, the maximum number of extensions that can be connected to the PBX is 64.
*3 One 8-channel PT-interface CS or IP-CS counts as 2 CSs, up to a maximum of 32 CSs. Therefore, the maximum number of CSs is 21 (eleven 2-channel CSs + ten 8-channel CSs).
*4 For the KX-NCP500, when using the DPH2 card, the maximum number of doorphones is 12.
KX-TDE Series
| Terminal Equipment Type | KX-TDE100 | KX-TDE200 | KX-TDE600 | |||
| Basic System | 2-shelf System | 3-shelf System | 4-shelf System | |||
| Telephone (using Digital XDP) | 256 | 256 | 368 (432)*1 | 608 (736)*1 | 848 (1008)*1 | 992 (1152)*1 |
|---|---|---|---|---|---|---|
| SLT | 128 | 168 | 240 | 480 | 720 | 960 |
| KX-DT300 / KX-T7600 series DPT | 128 | 256 | 256 | 512 | 640 | 640 |
| Other DPT | 32 | 128 | 128 | 256 | 384 | 512 |
| APT | 24 | 64 | 80 | 160 | 240 | 320 |
| IP-PT | 192 | 192 | 288 | 448 | 608 | 704 |
| IP-PT*2 (supported by IP-EXT16 card) | 96 | 128 | 160 | 320 | 480 | 640 |
| IP-PT*3 (supported by IPCEMPR card) | 128*4 | 128*4 | 128*4 | 128*4 | 128*4 | 128*4 |
| SIP Extension | 128 | 128 | 128 | 128 | 128 | 128 |
| DSS console | 8 | 8 | 64 | 64 | 64 | 64 |
| CS | 32*5 | 32*5 | 32*5 | 64*5 | 96*5 | 128*5 |
| PT interface CS (2-channel) / CS for CSIF card | 32 | 32 | 32 | 64 | 96 | 128 |
| PT interface CS (8-channel) | 16 | 16 | 16 | 32 | 48 | 64 |
| IP-CS (8-channel) | 16 | 16 | 16 | 16 | 16 | 16 |
| PS | 128 | 128 | 512 | 512 | 512 | 512 |
| Voice Processing System (VPS)*6 | 2 | 2 | 8 | 8 | 8 | 8 |
| Doorphone | 16 | 16 | 16 | 32 | 48 | 64 |
| Door Opener | 16 | 16 | 16 | 32 | 48 | 64 |
| External Sensor | 16 | 16 | 16 | 32 | 48 | 64 |
| External Relay | 16 | 16 | 16 | 32 | 48 | 64 |
Kx-tde100 Specifications Free Slots Vegas World
Scroll
*1 Even when Digital XDP is used, each shelf supports a maximum of 256 KX-DT300 / KX-t7600 series DPTs.
*2 KX-NT300 series (except KX-NT366/KX-NT305), KX-NT265, and KX-NT136.
*3 KX-NT400, KX-NT300 series, and KX-NT265 (software version 2.00 or later only).
*4 For the KX-NT400, the maximum number of extensions that can be connected to the PBX is 64.
*5 One 8-channel PT-interface CS or IP-CS counts as 2 CSs for the total number of CSs.
*6 Only a single VPS can be connected to one optional service card. Springbok casino deposit bonus codes.
